Historic Scotland (1998)
This is one variant — a specific cloth: this exact thread count and colourway, with its own provenance below. It is one weaving of the sett (the scale-free proportion — the same cloth at any scale or shade), whose colour order is pattern BWBBBBBBBBGBGBBBBBBBBW.
Sourced from register-of-tartans. It is a 22 stripe tartan.
Original link https://www.tartanregister.gov.uk/tartanDetails.aspx?ref=1739
3 attestations — the source records this cloth was collapsed from (oldest owns this page)
- 01/01/1998 — Historic Scotland (1998) (register-of-tartans, record)
A modification of its first corporate tartan #2122 (original Scottish Tartans Authority reference). Thought to have been designed by Betty Davies (Chief Designer for Scottish Fashion International of Edinburgh) and woven by D.C. Dalgliesh. - February 1998 — Historic Scotland (1998) (Corporate) (tartans-authority, record)
A modification of its first corporate tartan (#2122). Thought to have been designed by Betty Davies (Chief Designer for Scottish Fashion International of Edinburgh) and woven by D C Dalgliesh. - undated — Historic Scotland (weddslist, record)
Dataset — provenance for this record, inherited from the source manifest
- source
- Scottish Register of Tartans
- data captured from
- https://github.com/thetartan/tartan-database/blob/master/data/register-of-tartans/data.csv
- data date
- 1998 (this record)
- licence
- Crown copyright
Capture chain — the hands this data passed through, oldest first; each capture carries its own licence
- Scottish Register of Tartans · Crown copyright
the living register — still published by National Records of Scotland - thetartan/tartan-database 2016-2017 · CC BY-NC-ND 4.0
Levko Kravets's frozen compilation — the capture we vendored, and where its CC licence text came from - this dictionary captured 2026-06-10 · commit 5bf86c7566
each re-capture is a git commit to data/sources
Register references
External register numbers recorded for this tartan.
- Scottish Register of Tartans: 1739
- Scottish Tartans Authority (ITI): 2547
- Scottish Tartans World Register: 2547
Thread count
DB/8 W8 DB4 DP4 DB36 DP4 DB4 N26 DB2 N26 G2 DB5 G2 N26 DB2 N26 DB4 DP4 DB36 DP4 DB4 W/8
One full sett is 474 threads.
Palette
| Colour | Shade | OKLCh |
|---|---|---|
| DB | #082077 #082077 | oklch(30.0% 0.149 265.1) |
| G | #008B2A #008B2A | oklch(55.4% 0.170 145.9) |
| W | #F7F7F7 #F7F7F7 | oklch(97.6% 0.000 89.9) |
| N | #636363 #636363 | oklch(50.0% 0.000 89.9) |
| DP | #4B0B4F #4B0B4F | oklch(30.1% 0.125 325.4) |
Sample pattern
Nearest tartan variants
The nearest existing variants by ΔTartan distance, with this cloth at the top so the swatches line up against it.
Neighbour map
Every grey dot is one of 13621 variants placed by the first two principal components of the ΔTartan feature space (42% of its variance). Red is this tartan; blue dots are its nearest — click one to open its page.
ID: /variants/s12/db8w8db4dp4db36dp4db4n26db2n26g2db5/
